Power Supplies Switching Desktop Multi-Output w/PFC Module (Standard Option) Series 85-100 Watt
See Specification, Rating Table & Modular Concept for Desktop Power Supplies
Over 200 standard models, single, dual, triple and triple-low, output voltage from: 3.3V to 48V in 0.1V increment, single-platform design. This family of desktop style power supplies is housed in impact resistant polycarbonate enclosure with thermal conduction cooling. Case Dimensions: 5.60 x 3.00 x 1.7 (in), all models.
This family features: regulated output with low ripple single/dual/triple up to 100W, Remote Sensing, has built-in protection features: O.C./S.C., O.V., Thermal, accepts Universal Input:100-250VAC, meets Safety Agency Requirements: UL60950 and UL2601, and complies with EMI/RFI Regulations, EMC Directives / CE Compliant for Grounded and Non-Grounded Applications. Power Factor Correction (PFC) is available, standard option, to comply with EN61000-3-2 and EN61000-3-3. Modified and custom designs, such as: Constant Current, Battery Chargers, Internal Applications: PCB and Open Frame Mounted are also available. Made in USA option available upon request.
